D-SUB 19-Pin Female DB19 Solder Connector
Apple • Atari TT/Falcon • NeXT • Macintosh Compatible (New Old Stock)
SKU: DB19-F-SOLDER • Price reference: ~€4.50–£9.99 (NOS stock, subject to availability)
OUR PRICE IS THE LOWEST IN THE WORLD!
Genuine DB19 female solder-cup connector (New Old Stock). Shown above: typical metal shell with 19 precision solder pins.
Extremely rare — production of DB19 connectors ceased decades ago. These are authentic surplus parts.
Product Overview
Genuine DB19 female D-sub 19-pin solder socket/connector.
This hard-to-find connector was originally used in several iconic 1980s–1990s vintage computers and peripherals. It is the exact part needed for repairing or building custom cables for:
- Atari TT030 & Falcon030 – ACSI/DMA hard drive port and RGB SCART video cables
- Atari ST/STE series – ACSI (Atari Computer System Interface) port
- Apple Macintosh (early 68k models) & Apple IIc / II series – external floppy disk drive port
- NeXT Computer / NeXTstation / NeXTCube – monitor, laser printer, and peripheral cables
Key Specifications
| Connector Type | D-Sub (DB) 19-pin Female |
| Gender | Female (socket) |
| Connection Style | Solder cup (ideal for hand-wiring cables) |
| Shell | Standard metal D-sub with mounting flanges |
| Condition | New Old Stock (NOS) – never used, factory fresh |
| Compatibility | Atari TT/Falcon, Atari ST, Apple II/Mac, NeXT systems |
Example Pinout Reference (Atari ACSI / DMA Port)
(Pinouts vary by system — always verify your specific device wiring)
| Pin | Signal (Atari ACSI) | Pin | Signal (Atari ACSI) |
|---|---|---|---|
| 1 | Data 0 | 11 | Ground |
| 2 | Data 1 | 12 | Reset |
| 3 | Data 2 | 13 | Ground |
| 4 | Data 3 | 14 | Acknowledge |
| 5 | Data 4 | 15 | Ground |
| 6 | Data 5 | 16 | A |
| 7 | Data 6 | 17 | Ground |
| 8 | Data 7 | 18 | Read/Write |
| 9 | Chip Select | 19 | Data Request |
| 10 | Interrupt Request | (Apple floppy & NeXT pinouts differ – refer to system-specific diagrams) | |
What’s Included
1 × DB19 female solder-cup connector (New Old Stock)
